Power Supply

AC 208 -240V ( 50Hz or 60Hz can be selected in options bar ).

Max Power Input

800W

Cooling Capacity

5004W (17500Btu/hour)

Compressor

Rotary Compressor (1.68 KW)

Refrigerant

R22

Temperature Control

5~30 °C

Temperature Accuracy

± 0.3 °C

Heating Exchanger

Stainless steel

Water Flow Rate (Head Pressure)

58 Liter / minute    ( 28 meters high, 40psi )

Water Tank

15 Liters  made of stainless steel

Water chiller should not be connected to a system with the capacity more than the tank's capacity itself.

Use coolant instead of water for longer service life.

Do not use deionized water as the cooling agent, DI water may cause the copper pipe to corrode, mainly pitting, and leak over time.

Pipe Connection

Φ12mm PTC connector

8mm I.D, 12mm O.D. polyurethane tube is included

 Water Filter

One water filter is included for immediate use.

Replace water filter every 3 to 6 months based on water quality and usage. Please click pictures below to learn more.

    Noise

80dBA

    Protection

Protected from over-temperature and Min 2 L/min water flow

Overall Dimensions

60 X 47 X 89 cm

Shipping Weight

300 lbs

Compliance

CE approval

MET Certification (UL 1450) is available upon request at extra cost, please contact our sales representatives for a quote.

Warranty

One-year limited warranty with lifetime support

Application Notes

Must use Rust Protection coolants to prevent rust and corrosiom The use of tap water is prohibited.

Please connect the chiller water outlet to the equipment water inlet, and the chiller water inlet to the equipment outlet. Otherwise, the water flow sensor on the equipment may fail to work due to wrong water flow direction
