4. Process Performance

1. Real time processing of feedback control performance and waveform control function to achieve ideal welding conditions;

2. The combination design of galvanometer scanning head can realize spot welding and seam welding within the processing range;

3. Gradual in and gradual out function, and the overlapping parts at the beginning and end of seam welding are completed;

4. The setting of input and output connectors (signals) makes automation easier;

5. Standardized workbench design, simple and flexible welding fixture debugging;

6. The battery model has strong compatibility and is equipped with universal welding fixture;

7. PC control is easy to operate, with track teaching function and easy to use

8. It is equipped with three axes as standard, which can be expanded into four axes linkage to realize arbitrary three-dimensional welding in space;

9. Touch screen man-machine dialogue interface, humanized operation, simple and intuitive.

5.Brands of Main Components

6.Installation Environment Requirements

1. Configured Power Supply: AC380V, 50Hz,

Voltage Fluctuation Range: + 10% ～ - 10%;

2. Compressed Air: 0.2 ~ 0.8MPa, pressure fluctuation ± 1%

(clean air after water removal, oil-free, filtration and pressure stabilization);

3. Equipment Specification:

1) Equipment Weight: About 1000kg;

2) Overall Dimension: About L (1.5mm) * W (1.2mm) * H (1.6mm);

3) Appearance Color: Light gray.

4. Environmental Requirements:

1) Ambient Temperature: 25 ± 5 ℃;

2) Relative Humidity: 30% ~ 75% RCH, ensure that the on-site air is dry and unblocked without acid-base corrosion;

3) Ground Wire: Protective grounding;

4) Problems caused by disasters, war, abnormal weather or other force majeure.
