Power

3KW

5KW

7KW

9KW

13KW

18KW

Chamber size（mm）

160X150X150

200X200X200

300X200X200

300X250X250

400X300X300

500X400X400

Boundary dimension（mm）

550X515X905

590X555X995

590X655X985

640X655X1035

690X715X1125

834X902X1335

Supply voltage

220V

                  380V

Phase

Single phase

single phase

                 three phase

Heating element

                                               silicon carbide rod

Control mode

UAV program temperature control instrument

1, 30-stage program temperature control intelligent PID adjustment.

2. With over-temperature protection, the electric furnace heating circuit is automatically cut off when the temperature is over-temperature or broken. (When the electric furnace temperature exceeds 1420 degrees or the thermocouple is blown, the AC relay on the main circuit will be automatically disconnected and the main circuit will be disconnected. The ON light on the panel is off, the OFF light is on, and the limited protection electric furnace).

3, with 485 communication interface (standard when purchasing software)

4, with power-off protection function, that is, when the power is turned on after the power is turned off, the program does not start from the starting temperature, but the furnace temperature rises from the time of power failure.

5, the meter has the function of temperature self-tuning

(you need to pay extra for the replacement of imported instruments, optional)

FP93 temperature controller            European instrument                Touch screen instrument

(shimaden, Japan)

Furnace material

Type 1600 alumina polycrystalline fibre. Furnace material imported from Japan is available (additional charge is required for the selection of imported furnace material)

Control accuracy

                                               +/- 1℃

Trigger

                                         Phase-shifted trigger

Electric appliance

                                          Zhejiang chint

Silicon controlled

                                       106/16ESEMIKRON

Maximum temperature

                                                      1400℃

Rated temperature

                                                       1350℃

Heating rate

                    ≤20℃/ Min(it can be modified as required)

Recommended rate of temperature rise

                                                      ≤10℃/ Min

Thermocouple Type

                                                         S type

Identification

                                                             CE

Peripheral surface temperature

                                                           ≤45℃

Gas atmosphere

Maximum operating temperature in all atmospheres

air

1400

vacuum

900-1100

Nitrogen gas

1270

Hydrogen gas

1100

Hydrocarbon gas

1150

Argon

1300
