Modle

1400-I

1400-II

1400-III

1400-Ⅳ

1400-Ⅴ

1400-Ⅴ

Power

3 KW

5 KW

7KW

9 KW

12KW

18KW

Chamber（DXWXH）

160X150X150mm

200X200X200mm

300X200X200mm

300X250X250mm

400X300X300mm

500X400X400mm

Dimensions

520X490X880

564X530X930

600X630X970

620X630X1020

670X760X1110

840X870X1740

Supply voltage

220V

220V

220V

380V

380V

380V

Phase

single phase

three phase

Heating element

Silicon carbide rod

Control mode

UAV program temperature control instrument

1, 30-stage program temperature control intelligent PID adjustment.

2. With over-temperature protection, the electric furnace heating circuit is automatically cut off when the temperature is over-temperature or broken, (when the electric furnace temperature exceeds 1420 degrees or the thermocouple is blown, the AC relay on the main circuit will be automatically disconnected, the main circuit is broken. On, the ON light on the panel is off, the OFF light is on, and the limited protection electric furnace).

3, with 485 communication interface (standard when purchasing software)

4, with power-off protection function, that is, when the power is turned on after the power is turned off, the program does not start from the starting temperature, but the furnace temperature rises from the time of power failure.

5, the meter has the function of temperature self-tuning

Heating rate

                                   ≤30℃/ Min

Recommended rate of temperature rise

                                   15℃/ Min

Chamber material

               1600 alumina polycrystalline fiber

Control precision

                                         +/- 1℃

Maximum temperature

                                       1400℃

Rated temperature

                                       1350℃

Peripheral surface temperature

                                       ≤35℃

Thermocouple Type

                                            S

Trigger

                              Phase-shifted trigger

Electric appliance

                                     Zhejiang chint

Silicon controlled

                            106/16ESEMIKRON

Travel switch

A travel switch is installed on the furnace door. When the furnace door is opened, the power supply is automatically cut off to prevent the risk of electric shock from hitting the heating element.
